SRR1240-3R9M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 3.9UH 6.35A 15MOHM SMD
- CategoryFixed Inductors
- Datasheet SRR1240-3R9M Datasheet
-
ECAD Model
- Share
In Stock: 137
Can ship immediately
Pricing:
- 1$0.527
- 800$0.527
Quote It
Technical Details
- Series:SRR1240
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:3.9 µH
- Tolerance:±20%
- Current Rating (Amps):6.35 A
- Current - Saturation (Isat):6.2A
- Shielding:Shielded
- DC Resistance (DCR):15mOhm Max
- Q @ Freq:14 @ 7.96MHz
- Frequency - Self Resonant:39MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.492" L x 0.492" W (12.50mm x 12.50mm)
- Height - Seated (Max):0.177" (4.50mm)
