IDC5020ER2R2M
Vishay / Dale
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 6.1A 12 MOHM SMD
- CategoryFixed Inductors
- Datasheet IDC5020ER2R2M Datasheet
-
ECAD Model
- Share
In Stock: 118
Can ship immediately
Pricing:
- 1$0.54
- 500$0.54
- 1,000$0.48
- 2,500$0.465
- 5,000$0.45
- 12,500$0.435
Quote It
Technical Details
- Series:IDC-5020
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:2.2 µH
- Tolerance:±20%
- Current Rating (Amps):6.1 A
- Current - Saturation (Isat):7A
- Shielding:Unshielded
- DC Resistance (DCR):12mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.510" L x 0.370" W (12.95mm x 9.40mm)
- Height - Seated (Max):0.205" (5.21mm)
