PM3308-681M-RC
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 680UH 100MA 5.3OHM SMD
- CategoryFixed Inductors
- Datasheet PM3308-681M-RC Datasheet
-
ECAD Model
- Share
In Stock: 174
Can ship immediately
Pricing:
- 1$0.544
- 1,000$0.544
Quote It
Technical Details
- Series:PM3308
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:680 µH
- Tolerance:±20%
- Current Rating (Amps):100 mA
- Current - Saturation (Isat):200mA
- Shielding:Unshielded
- DC Resistance (DCR):5.3Ohm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.512" L x 0.374" W (13.00mm x 9.50mm)
- Height - Seated (Max):0.118" (3.00mm)
