B82442T1335K050

Technical Details

• Series:SIMID
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:3.3 mH
• Tolerance:±10%
• Current Rating (Amps):85 mA
• Current - Saturation (Isat):138mA
• Shielding:Unshielded
• DC Resistance (DCR):32.8Ohm Max

• Q @ Freq:30 @ 252kHz
• Frequency - Self Resonant:1MHz
• Ratings:AEC-Q200
• Operating Temperature:-
• Inductance Frequency - Test:252 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:2-SMD, J-Lead
• Supplier Device Package:2220 (5650 Metric)
• Size / Dimension:0.220" L x 0.197" W (5.60mm x 5.00mm)
• Height - Seated (Max):0.209" (5.30mm)
