B82471A1683K000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 68UH 610MA 460 MOHM
- CategoryFixed Inductors
- Datasheet B82471A1683K000 Datasheet
-
ECAD Model
- Share
In Stock: 143
Can ship immediately
Pricing:
- 1$0.552
- 2,000$0.552
Quote It
Technical Details
- Series:B82471A1
- Package:Tape & Reel (TR)
- Part Status:Not For New Designs
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:68 µH
- Tolerance:±10%
- Current Rating (Amps):610 mA
- Current - Saturation (Isat):700mA
- Shielding:Unshielded
- DC Resistance (DCR):460mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.240" L x 0.220" W (6.10mm x 5.60mm)
- Height - Seated (Max):0.193" (4.90mm)
