PA3784.121HLT
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 120NH 70A 0.18 MOHM
- CategoryFixed Inductors
- Datasheet PA3784.121HLT Datasheet
-
ECAD Model
- Share
In Stock: 198
Can ship immediately
Pricing:
- 1$0.5859
- 3,150$0.5859
Quote It
Technical Details
- Series:PA3784.XXXHL
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:-
- Material - Core:-
- Inductance:120 nH
- Tolerance:±10%
- Current Rating (Amps):70 A
- Current - Saturation (Isat):94A
- Shielding:Unshielded
- DC Resistance (DCR):0.18mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 130°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.394" L x 0.315" W (10.00mm x 8.00mm)
- Height - Seated (Max):0.315" (8.00mm)
