SDR1806-8R2ML

Technical Details

• Series:SDR1806
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:8.2 µH
• Tolerance:±20%
• Current Rating (Amps):7 A
• Current - Saturation (Isat):9.4A
• Shielding:Unshielded
• DC Resistance (DCR):20mOhm Max

• Q @ Freq:22 @ 7.96MHz
• Frequency - Self Resonant:27MHz
• Ratings:-
• Operating Temperature:-40°C ~ 125°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.720" L x 0.551" W (18.30mm x 14.00mm)
• Height - Seated (Max):0.272" (6.90mm)
