PA4546.222NLT
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 2.8A 80 MOHM SMD
- CategoryFixed Inductors
- Datasheet PA4546.222NLT Datasheet
-
ECAD Model
- Share
In Stock: 108
Can ship immediately
Pricing:
- 1$0.5735
- 4,000$0.5735
Quote It
Technical Details
- Series:PA4546.XXXNLT
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Molded
- Material - Core:-
- Inductance:2.2 µH
- Tolerance:±20%
- Current Rating (Amps):2.8 A
- Current - Saturation (Isat):3.5A
- Shielding:Unshielded
- DC Resistance (DCR):80mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.175" L x 0.160" W (4.45mm x 4.06mm)
- Height - Seated (Max):0.047" (1.20mm)
