9230-46-RC

Technical Details

• Series:9230
• Package:Bulk
• Part Status:Active
• Type:Molded
• Material - Core:Ferrite
• Inductance:12 µH
• Tolerance:±10%
• Current Rating (Amps):210 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):2.7Ohm Max

• Q @ Freq:45 @ 2.5MHz
• Frequency - Self Resonant:40MHz
• Ratings:-
• Operating Temperature:-55°C ~ 125°C
• Inductance Frequency - Test:2.5 MHz
• Features:-
• Mounting Type:Through Hole
• Package / Case:Axial
• Supplier Device Package:-
• Size / Dimension:0.095" Dia x 0.250" L (2.41mm x 6.35mm)
• Height - Seated (Max):-
