VLF302512MT-150M
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 15UH 800MA 448 MOHM
- CategoryFixed Inductors
- Datasheet VLF302512MT-150M Datasheet
-
ECAD Model
- Share
In Stock: 133
Can ship immediately
Pricing:
- 1$0.584
- 2,000$0.584
- 4,000$0.56575
- 6,000$0.5475
- 10,000$0.52925
Quote It
Technical Details
- Series:VLF-MT
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:15 µH
- Tolerance:±20%
- Current Rating (Amps):800 mA
- Current - Saturation (Isat):570mA
- Shielding:Shielded
- DC Resistance (DCR):448mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.118" L x 0.098" W (3.00mm x 2.50mm)
- Height - Seated (Max):0.047" (1.20mm)
