PA4302.102NLT
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1UH 7.5A 20 MOHM SMD
- CategoryFixed Inductors
- Datasheet PA4302.102NLT Datasheet
-
ECAD Model
- Share
In Stock: 141
Can ship immediately
Pricing:
- 1$0.6045
- 3,600$0.6045
Quote It
Technical Details
- Series:PA4302.XXXNLT
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:1 µH
- Tolerance:±30%
- Current Rating (Amps):7.5 A
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):20mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.295" L x 0.295" W (7.50mm x 7.50mm)
- Height - Seated (Max):0.220" (5.60mm)
