TPL1254035-712J-708N
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 7.08MH 45 OHM SMD
- CategoryFixed Inductors
- Datasheet TPL1254035-712J-708N Datasheet
-
ECAD Model
- Share
In Stock: 141
Can ship immediately
Pricing:
- 1$0.61225
- 2,500$0.61225
Quote It
Technical Details
- Series:TPL
- Package:Tape & Reel (TR)
- Part Status:Not For New Designs
- Type:-
- Material - Core:-
- Inductance:7.08 mH
- Tolerance:±5%
- Current Rating (Amps):-
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):45Ohm
- Q @ Freq:72 @ 125kHz
- Frequency - Self Resonant:800kHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:125 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.492" L x 0.154" W (12.50mm x 3.90mm)
- Height - Seated (Max):0.146" (3.70mm)
