ISC1812RV180K
Vishay / Dale
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 18UH 238MA 1.24 OHM
- CategoryFixed Inductors
- Datasheet ISC1812RV180K Datasheet
-
ECAD Model
- Share
In Stock: 114
Can ship immediately
Pricing:
- 1$0.6208
- 1,000$0.6208
- 2,500$0.6014
- 5,000$0.582
- 12,500$0.5626
Quote It
Technical Details
- Series:ISC-1812
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Iron Powder
- Inductance:18 µH
- Tolerance:±10%
- Current Rating (Amps):238 mA
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):1.24Ohm Max
- Q @ Freq:50 @ 2.52MHz
- Frequency - Self Resonant:15MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:2.52 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1812 (4532 Metric)
- Supplier Device Package:1812
- Size / Dimension:0.177" L x 0.126" W (4.50mm x 3.20mm)
- Height - Seated (Max):0.134" (3.40mm)
