PM1608-3R3M-RC
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 3.3UH 2A 80 MOHM SMD
- CategoryFixed Inductors
- Datasheet PM1608-3R3M-RC Datasheet
-
ECAD Model
- Share
In Stock: 142
Can ship immediately
Pricing:
- 1$0.63
- 600$0.63
Quote It
Technical Details
- Series:PM1608
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:3.3 µH
- Tolerance:±20%
- Current Rating (Amps):2 A
- Current - Saturation (Isat):2A
- Shielding:Unshielded
- DC Resistance (DCR):80mOhm Max
- Q @ Freq:18.5 @ 7.96MHz
- Frequency - Self Resonant:70MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:7.96 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.260" L x 0.175" W (6.60mm x 4.45mm)
- Height - Seated (Max):0.115" (2.92mm)
