PM428S-330-RC
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 33UH 820MA 230MOHM SMD
- CategoryFixed Inductors
- Datasheet PM428S-330-RC Datasheet
-
ECAD Model
- Share
In Stock: 144
Can ship immediately
Pricing:
- 1$0.68
- 2,000$0.68
Quote It
Technical Details
- Series:PM428S
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:33 µH
- Tolerance:±30%
- Current Rating (Amps):820 mA
- Current - Saturation (Isat):580mA
- Shielding:Shielded
- DC Resistance (DCR):230mOhm Max
- Q @ Freq:9.7 @ 2.52MHz
- Frequency - Self Resonant:16MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.189" L x 0.189" W (4.80mm x 4.80mm)
- Height - Seated (Max):0.118" (3.00mm)
