MGV1004R19N-10
Laird - Performance Materials
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 190NH 36A 0.9MOHM SMD
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 162
Can ship immediately
Pricing:
- 1$0.67323
Quote It
Technical Details
- Series:MGV
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Molded
- Material - Core:-
- Inductance:190 nH
- Tolerance:±30%
- Current Rating (Amps):36 A
- Current - Saturation (Isat):70A
- Shielding:Shielded
- DC Resistance (DCR):0.9mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.433" L x 0.394" W (11.00mm x 10.00mm)
- Height - Seated (Max):0.173" (4.40mm)
