PM42S-220-RC

Technical Details

• Series:PM42S
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:22 µH
• Tolerance:±30%
• Current Rating (Amps):880 mA
• Current - Saturation (Isat):650mA
• Shielding:Shielded
• DC Resistance (DCR):300mOhm Max

• Q @ Freq:7 @ 2.52MHz
• Frequency - Self Resonant:29MHz
• Ratings:-
• Operating Temperature:-40°C ~ 125°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.189" L x 0.189" W (4.80mm x 4.80mm)
• Height - Seated (Max):0.118" (3.00mm)
