RL855-681K-RC
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 680UH 320MA 3.25OHM TH
- CategoryFixed Inductors
- Datasheet RL855-681K-RC Datasheet
-
ECAD Model
- Share
In Stock: 158
Can ship immediately
Pricing:
- 1$0.7056
- 1,000$0.672
Quote It
Technical Details
- Series:RL855
- Package:Bulk
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:680 µH
- Tolerance:±10%
- Current Rating (Amps):320 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):3.25Ohm Max
- Q @ Freq:34 @ 790kHz
- Frequency - Self Resonant:1.7MHz
- Ratings:-
- Operating Temperature:-30°C ~ 100°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder (Open)
- Supplier Device Package:-
- Size / Dimension:0.307" Dia (7.80mm)
- Height - Seated (Max):0.217" (5.50mm)
