UP2UC-151-R

Technical Details

• Series:UNI-PAC™ 2UC
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Wirewound
• Material - Core:-
• Inductance:150 µH
• Tolerance:±20%
• Current Rating (Amps):1 A
• Current - Saturation (Isat):1A
• Shielding:Unshielded
• DC Resistance (DCR):400mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:6MHz
• Ratings:-
• Operating Temperature:-25°C ~ 85°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.500" L x 0.394" W (12.70mm x 10.00mm)
• Height - Seated (Max):0.205" (5.21mm)
