B82442A1825J000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 8.2MH 28MA 100 OHM SMD
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 159
Can ship immediately
Pricing:
- 1$1.82
- 1,500$0.82974
- 3,000$0.80382
- 7,500$0.77789
- 10,500$0.75196
Quote It
Technical Details
- Series:SIMID
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Last Time Buy
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:8.2 mH
- Tolerance:±5%
- Current Rating (Amps):28 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):100Ohm Max
- Q @ Freq:30 @ 252kHz
- Frequency - Self Resonant:600kHz
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:252 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:2-SMD, J-Lead
- Supplier Device Package:2220 (5650 Metric)
- Size / Dimension:0.220" L x 0.197" W (5.60mm x 5.00mm)
- Height - Seated (Max):0.209" (5.30mm)
