PM127SH-681M-RC
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 680UH 750MA 1.3OHM SMD
- CategoryFixed Inductors
- Datasheet PM127SH-681M-RC Datasheet
-
ECAD Model
- Share
In Stock: 195
Can ship immediately
Pricing:
- 1$0.735
- 400$0.735
Quote It
Technical Details
- Series:PM127SH
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:680 µH
- Tolerance:±20%
- Current Rating (Amps):750 mA
- Current - Saturation (Isat):970mA
- Shielding:Shielded
- DC Resistance (DCR):1.3Ohm Max
- Q @ Freq:26 @ 796kHz
- Frequency - Self Resonant:1.7MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.492" L x 0.492" W (12.50mm x 12.50mm)
- Height - Seated (Max):0.315" (8.00mm)
