MPIA4020V2-R56-R
PowerStor (Eaton)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 560NH 8A 15 MOHM SMD
- CategoryFixed Inductors
- Datasheet MPIA4020V2-R56-R Datasheet
-
ECAD Model
- Share
In Stock: 133
Can ship immediately
Pricing:
- 1$0.74555
- 3,000$0.74555
Quote It
Technical Details
- Series:MPIA40-V2
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Molded
- Material - Core:Metal Composite
- Inductance:560 nH
- Tolerance:±20%
- Current Rating (Amps):8 A
- Current - Saturation (Isat):10A
- Shielding:Shielded
- DC Resistance (DCR):15mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:87MHz
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:2-SMD, J-Lead
- Supplier Device Package:-
- Size / Dimension:0.195" L x 0.165" W (4.95mm x 4.20mm)
- Height - Seated (Max):0.079" (2.00mm)
