PF0601.552NLT
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 5.5UH 1.5A 75 MOHM SMD
- CategoryFixed Inductors
- Datasheet PF0601.552NLT Datasheet
-
ECAD Model
- Share
In Stock: 109
Can ship immediately
Pricing:
- 1$0.752
- 2,400$0.752
Quote It
Technical Details
- Series:PF0601NL
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:5.5 µH
- Tolerance:±20%
- Current Rating (Amps):1.5 A
- Current - Saturation (Isat):1.5A
- Shielding:Shielded
- DC Resistance (DCR):75mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:40MHz
- Ratings:-
- Operating Temperature:-40°C ~ 130°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.272" L x 0.256" W (6.90mm x 6.50mm)
- Height - Seated (Max):0.118" (3.00mm)
