IHLP3232DZER220M5A
Vishay / Dale
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 3.7A 110.21 MOHM
- CategoryFixed Inductors
- Datasheet IHLP3232DZER220M5A Datasheet
-
ECAD Model
- Share
In Stock: 126
Can ship immediately
Pricing:
- 1$0.8316
- 500$0.8316
- 1,000$0.75822
- 2,500$0.73377
- 5,000$0.7093
- 12,500$0.68485
Quote It
Technical Details
- Series:IHLP-3232DZ-5A
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Molded
- Material - Core:-
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):3.7 A
- Current - Saturation (Isat):3.8A
- Shielding:Shielded
- DC Resistance (DCR):110.21mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:9MHz
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.322" L x 0.322" W (8.18mm x 8.18mm)
- Height - Seated (Max):0.157" (4.00mm)
