NS12555T152MNV
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.5MH 440MA 1.73 OHM
- CategoryFixed Inductors
- Datasheet NS12555T152MNV Datasheet
-
ECAD Model
- Share
In Stock: 127
Can ship immediately
Pricing:
- 1$0.84339
- 2,000$0.84339
Quote It
Technical Details
- Series:NS
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:1.5 mH
- Tolerance:±20%
- Current Rating (Amps):440 mA
- Current - Saturation (Isat):400mA
- Shielding:Shielded
- DC Resistance (DCR):1.73Ohm Max
- Q @ Freq:-
- Frequency - Self Resonant:1.7MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:125125
- Size / Dimension:0.492" L x 0.492" W (12.50mm x 12.50mm)
- Height - Seated (Max):0.230" (5.85mm)
