#B953AS-561M=P3
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 560UH 640MA 900 MOHM
- CategoryFixed Inductors
- Datasheet #B953AS-561M=P3 Datasheet
-
ECAD Model
- Share
In Stock: 155
Can ship immediately
Pricing:
- 1$0.76806
- 500$0.76806
- 1,000$0.68272
- 2,500$0.66138
- 5,000$0.64005
- 12,500$0.61872
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:560 µH
- Tolerance:±20%
- Current Rating (Amps):640 mA
- Current - Saturation (Isat):620mA
- Shielding:Shielded
- DC Resistance (DCR):900mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.504" L x 0.504" W (12.80mm x 12.80mm)
- Height - Seated (Max):0.268" (6.80mm)
