PM3316S-220M-RC
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 1.4A 100 MOHM SMD
- CategoryFixed Inductors
- Datasheet PM3316S-220M-RC Datasheet
-
ECAD Model
- Share
In Stock: 103
Can ship immediately
Pricing:
- 1$0.799
- 500$0.799
Quote It
Technical Details
- Series:PM3316S
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):1.4 A
- Current - Saturation (Isat):1.9A
- Shielding:Shielded
- DC Resistance (DCR):100mOhm
- Q @ Freq:42 @ 2.52MHz
- Frequency - Self Resonant:18MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.500" L x 0.394" W (12.70mm x 10.00mm)
- Height - Seated (Max):0.205" (5.20mm)
