CDR125NP-100MC

Technical Details

• Series:CDR125
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:-
• Material - Core:-
• Inductance:10 µH
• Tolerance:±20%
• Current Rating (Amps):2.65 A
• Current - Saturation (Isat):-
• Shielding:Shielded
• DC Resistance (DCR):50mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:24.2MHz
• Ratings:-
• Operating Temperature:-40°C ~ 100°C
• Inductance Frequency - Test:2.52 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.496" L x 0.457" W (12.60mm x 11.60mm)
• Height - Seated (Max):0.232" (5.90mm)
