SDR2207-561KL
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 560UH 800MA 1 OHM SMD
- CategoryFixed Inductors
- Datasheet SDR2207-561KL Datasheet
-
ECAD Model
- Share
In Stock: 137
Can ship immediately
Pricing:
- 1$0.8316
- 250$0.74972
- 500$0.6426
- 750$0.60691
- 1,250$0.5712
- 2,500$0.5586
Quote It
Technical Details
- Series:SDR2207
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:560 µH
- Tolerance:±10%
- Current Rating (Amps):800 mA
- Current - Saturation (Isat):1.3A
- Shielding:Unshielded
- DC Resistance (DCR):1Ohm Max
- Q @ Freq:18 @ 1MHz
- Frequency - Self Resonant:4.5MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.866" L x 0.591" W (22.00mm x 15.00mm)
- Height - Seated (Max):0.307" (7.80mm)
