FP0705R3-R12-R

Technical Details

• Series:FLAT-PAC, FP0705
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:120 nH
• Tolerance:±10%
• Current Rating (Amps):32 A
• Current - Saturation (Isat):37A
• Shielding:Unshielded
• DC Resistance (DCR):0.46mOhm

• Q @ Freq:-
• Frequency - Self Resonant:-
• Ratings:-
• Operating Temperature:-40°C ~ 125°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.276" L x 0.276" W (7.00mm x 7.00mm)
• Height - Seated (Max):0.195" (4.95mm)
