PA5002.801NLT
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 800NH 13A 11.8 MOHM
- CategoryFixed Inductors
- Datasheet PA5002.801NLT Datasheet
-
ECAD Model
- Share
In Stock: 129
Can ship immediately
Pricing:
- 1$0.84
- 3,000$0.84
Quote It
Technical Details
- Series:PA5002.XXXNLT
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Molded
- Material - Core:Ferrite
- Inductance:800 nH
- Tolerance:±20%
- Current Rating (Amps):13 A
- Current - Saturation (Isat):15.5A
- Shielding:Shielded
- DC Resistance (DCR):11.8mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.217" L x 0.209" W (5.50mm x 5.30mm)
- Height - Seated (Max):0.083" (2.10mm)
