IMC1210EB820K

Technical Details

• Series:IMC-1210
• Package:Bulk
• Part Status:Active
• Type:Wirewound
• Material - Core:Iron Powder
• Inductance:82 µH
• Tolerance:±10%
• Current Rating (Amps):79 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):12Ohm Max

• Q @ Freq:30 @ 2.52MHz
• Frequency - Self Resonant:10MHz
• Ratings:-
• Operating Temperature:-55°C ~ 125°C
• Inductance Frequency - Test:2.52 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:1210 (3225 Metric)
• Supplier Device Package:1210
• Size / Dimension:0.126" L x 0.098" W (3.20mm x 2.49mm)
• Height - Seated (Max):0.095" (2.41mm)
