NS12575T221MNV
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 220UH 1.35A 294 MOHM
- CategoryFixed Inductors
- Datasheet NS12575T221MNV Datasheet
-
ECAD Model
- Share
In Stock: 194
Can ship immediately
Pricing:
- 1$0.85281
- 500$0.85281
- 1,000$0.77756
- 2,500$0.75248
- 5,000$0.7274
- 12,500$0.70231
Quote It
Technical Details
- Series:NS
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:220 µH
- Tolerance:±20%
- Current Rating (Amps):1.35 A
- Current - Saturation (Isat):1.81A
- Shielding:Shielded
- DC Resistance (DCR):294mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:2.9MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.492" L x 0.492" W (12.50mm x 12.50mm)
- Height - Seated (Max):0.309" (7.85mm)
