IHLW4040CFERR56M11
Vishay / Dale- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 560NH 30.5A 1.81 MOHM
- CategoryFixed Inductors
- Datasheet IHLW4040CFERR56M11 Datasheet
-
ECAD Model
- Share
In Stock: 110
Can ship immediately
Pricing:
- 1$0.864
- 500$0.864
- 1,000$0.768
- 2,500$0.744
- 5,000$0.72
- 12,500$0.696
Quote It
Technical Details
- Series:IHLW-4040CF-11
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:-
- Material - Core:-
- Inductance:560 nH
- Tolerance:±20%
- Current Rating (Amps):30.5 A
- Current - Saturation (Isat):23A
- Shielding:Shielded
- DC Resistance (DCR):1.81mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.400" L x 0.400" W (10.16mm x 10.16mm)
- Height - Seated (Max):0.142" (3.60mm)
