HCMA0503-220-R
PowerStor (Eaton)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 1.9A 270 MOHM SMD
- CategoryFixed Inductors
- Datasheet HCMA0503-220-R Datasheet
-
ECAD Model
- Share
In Stock: 117
Can ship immediately
Pricing:
- 1$0.95992
- 2,000$0.95992
Quote It
Technical Details
- Series:HCMA0503
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:-
- Material - Core:Iron Powder
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):1.9 A
- Current - Saturation (Isat):1.9A
- Shielding:Shielded
- DC Resistance (DCR):270mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.203" L x 0.201" W (5.15mm x 5.10mm)
- Height - Seated (Max):0.118" (3.00mm)
