IHLW5050CEER5R6M01
Vishay / Dale- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 5.6UH 9.5A 19 MOHM SMD
- CategoryFixed Inductors
- Datasheet IHLW5050CEER5R6M01 Datasheet
-
ECAD Model
- Share
In Stock: 151
Can ship immediately
Pricing:
- 1$0.882
- 500$0.882
- 1,000$0.784
- 2,500$0.7595
- 5,000$0.735
- 12,500$0.7105
Quote It
Technical Details
- Series:IHLW-5050CE-01
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:-
- Material - Core:-
- Inductance:5.6 µH
- Tolerance:±20%
- Current Rating (Amps):9.5 A
- Current - Saturation (Isat):19A
- Shielding:Shielded
- DC Resistance (DCR):19mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.500" L x 0.500" W (12.70mm x 12.70mm)
- Height - Seated (Max):0.138" (3.50mm)
