SD7030-1R5-R
PowerStor (Eaton)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.5UH 5.5A 12 MOHM SMD
- CategoryFixed Inductors
- Datasheet SD7030-1R5-R Datasheet
-
ECAD Model
- Share
In Stock: 191
Can ship immediately
Pricing:
- 1$0.8928
- 1,500$0.85715
Quote It
Technical Details
- Series:SD7030
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:1.5 µH
- Tolerance:±30%
- Current Rating (Amps):5.5 A
- Current - Saturation (Isat):4.5A
- Shielding:Shielded
- DC Resistance (DCR):12mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.276" L x 0.276" W (7.00mm x 7.00mm)
- Height - Seated (Max):0.118" (3.00mm)
