8230-04-RC

Technical Details

• Series:8230
• Package:Bulk
• Part Status:Active
• Type:Wirewound
• Material - Core:Phenolic
• Inductance:220 nH
• Tolerance:±10%
• Current Rating (Amps):935 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):140mOhm Max

• Q @ Freq:33 @ 25MHz
• Frequency - Self Resonant:510MHz
• Ratings:-
• Operating Temperature:-55°C ~ 105°C
• Inductance Frequency - Test:25 MHz
• Features:-
• Mounting Type:Through Hole
• Package / Case:Axial
• Supplier Device Package:-
• Size / Dimension:0.120" Dia x 0.300" L (3.05mm x 7.62mm)
• Height - Seated (Max):-
