9250A-563-RC
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 56UH 190MA 2.23 OHM TH
- CategoryFixed Inductors
- Datasheet 9250A-563-RC Datasheet
-
ECAD Model
- Share
In Stock: 194
Can ship immediately
Pricing:
- 1$0.89512
- 1,000$0.73624
Quote It
Technical Details
- Series:9250A
- Package:Bulk
- Part Status:Active
- Type:Molded
- Material - Core:Ferrite
- Inductance:56 µH
- Tolerance:±10%
- Current Rating (Amps):190 mA
- Current - Saturation (Isat):160mA
- Shielding:Shielded
- DC Resistance (DCR):2.23Ohm Max
- Q @ Freq:50 @ 2.5MHz
- Frequency - Self Resonant:25MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:2.5 MHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Axial
- Supplier Device Package:-
- Size / Dimension:0.162" Dia x 0.410" L (4.11mm x 10.41mm)
- Height - Seated (Max):-
