P1172.153NLT
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 15UH 4.1A 35.4 MOHM
- CategoryFixed Inductors
- Datasheet P1172.153NLT Datasheet
-
ECAD Model
- Share
In Stock: 124
Can ship immediately
Pricing:
- 1$0.9145
- 2,000$0.9145
Quote It
Technical Details
- Series:P1172NL
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:15 µH
- Tolerance:±20%
- Current Rating (Amps):4.1 A
- Current - Saturation (Isat):4.4A
- Shielding:Shielded
- DC Resistance (DCR):35.4mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:15MHz
- Ratings:-
- Operating Temperature:-40°C ~ 130°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.482" L x 0.482" W (12.24mm x 12.24mm)
- Height - Seated (Max):0.315" (8.00mm)
