AL12A12N5GTR
Elco (AVX)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 12.5NH 4A 3.4 MOHM SMD
- CategoryFixed Inductors
- Datasheet AL12A12N5GTR Datasheet
-
ECAD Model
- Share
In Stock: 186
Can ship immediately
Pricing:
- 1$0.9163
- 500$0.9163
Quote It
Technical Details
- Series:AL
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Air
- Inductance:12.5 nH
- Tolerance:±2%
- Current Rating (Amps):4 A
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):3.4mOhm Max
- Q @ Freq:137 @ 150MHz
- Frequency - Self Resonant:3.3GHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:150 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.145" L x 0.120" W (3.68mm x 3.05mm)
- Height - Seated (Max):0.125" (3.18mm)
