1812-390M
API Delevan
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 39NH 870MA 200 MOHM
- CategoryFixed Inductors
- Datasheet 1812-390M Datasheet
-
ECAD Model
- Share
In Stock: 158
Can ship immediately
Pricing:
- 1$0.9214
- 500$0.855
Quote It
Technical Details
- Series:1812
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:-
- Material - Core:Phenolic
- Inductance:39 nH
- Tolerance:±20%
- Current Rating (Amps):870 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):200mOhm Max
- Q @ Freq:30 @ 50MHz
- Frequency - Self Resonant:1GHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:50 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1812 (4532 Metric)
- Supplier Device Package:1812
- Size / Dimension:0.177" L x 0.126" W (4.50mm x 3.20mm)
- Height - Seated (Max):0.134" (3.40mm)
