ATCA-02-220M-H
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 5A 14 MOHM TH
- CategoryFixed Inductors
- Datasheet ATCA-02-220M-H Datasheet
-
ECAD Model
- Share
In Stock: 199
Can ship immediately
Pricing:
- 1$1.01779
- 2,000$1.01779
Quote It
Technical Details
- Series:ATCA
- Package:Tray
- Part Status:Active
- Type:Toroidal
- Material - Core:Iron Powder
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):5 A
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):14mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Horizontal (Open)
- Supplier Device Package:-
- Size / Dimension:0.866" Dia (22.00mm)
- Height - Seated (Max):0.492" (12.50mm)
