SD6020-390-R
PowerStor (Eaton)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 39UH 630MA 500 MOHM
- CategoryFixed Inductors
- Datasheet SD6020-390-R Datasheet
-
ECAD Model
- Share
In Stock: 122
Can ship immediately
Pricing:
- 1$1.023
- 2,600$0.9825
Quote It
Technical Details
- Series:SD6020
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:39 µH
- Tolerance:±30%
- Current Rating (Amps):630 mA
- Current - Saturation (Isat):570mA
- Shielding:Shielded
- DC Resistance (DCR):500mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.236" L x 0.236" W (6.00mm x 6.00mm)
- Height - Seated (Max):0.079" (2.00mm)
