1537-02K
API Delevan
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 220NH 2.02A 55 MOHM TH
- CategoryFixed Inductors
- Datasheet 1537-02K Datasheet
-
ECAD Model
- Share
In Stock: 160
Can ship immediately
Pricing:
- 1$1.10565
- 2,500$0.90878
Quote It
Technical Details
- Series:1537
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Molded
- Material - Core:Phenolic
- Inductance:220 nH
- Tolerance:±10%
- Current Rating (Amps):2.02 A
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):55mOhm Max
- Q @ Freq:50 @ 25MHz
- Frequency - Self Resonant:450MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:25 MHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Axial
- Supplier Device Package:-
- Size / Dimension:0.156" Dia x 0.375" L (3.96mm x 9.53mm)
- Height - Seated (Max):-
