784773068
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8UH 1.54A 131 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 171
Can ship immediately
Pricing:
- 1$1.075
- 1,500$1.075
Quote It
Technical Details
- Series:WE-PD2A
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:6.8 µH
- Tolerance:±20%
- Current Rating (Amps):1.54 A
- Current - Saturation (Isat):2.1A
- Shielding:Unshielded
- DC Resistance (DCR):131mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:35MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:10 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:4532
- Size / Dimension:0.177" L x 0.157" W (4.50mm x 4.00mm)
- Height - Seated (Max):0.138" (3.50mm)
