AX02-303R9
Triad Magnetics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 3.9UH 10A 6.8 MOHM SMD
- CategoryFixed Inductors
- Datasheet AX02-303R9 Datasheet
-
ECAD Model
- Share
In Stock: 189
Can ship immediately
Pricing:
- 1$1.08
- 480$1.07263
Quote It
Technical Details
- Series:AX02
- Package:Box
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:3.9 µH
- Tolerance:±20%
- Current Rating (Amps):10 A
- Current - Saturation (Isat):18A
- Shielding:Shielded
- DC Resistance (DCR):6.8mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:2-SMD, J-Lead
- Supplier Device Package:SMD
- Size / Dimension:0.524" L x 0.591" W (13.30mm x 15.00mm)
- Height - Seated (Max):0.256" (6.50mm)
