PA0515.271NLT
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 270NH 35A 0.63 MOHM
- CategoryFixed Inductors
- Datasheet PA0515.271NLT Datasheet
-
ECAD Model
- Share
In Stock: 166
Can ship immediately
Pricing:
- 1$1.085
- 1,750$1.085
Quote It
Technical Details
- Series:PA0515NL
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:-
- Material - Core:-
- Inductance:270 nH
- Tolerance:±20%
- Current Rating (Amps):35 A
- Current - Saturation (Isat):50A
- Shielding:Shielded
- DC Resistance (DCR):0.63mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 130°C
- Inductance Frequency - Test:-
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.440" L x 0.440" W (11.18mm x 11.18mm)
- Height - Seated (Max):0.354" (9.00mm)
