PF0504.333NLT
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 33UH 4.4A 42 MOHM SMD
- CategoryFixed Inductors
- Datasheet PF0504.333NLT Datasheet
-
ECAD Model
- Share
In Stock: 118
Can ship immediately
Pricing:
- 1$1.147
- 1,440$1.147
Quote It
Technical Details
- Series:PF0504NL
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:33 µH
- Tolerance:±20%
- Current Rating (Amps):4.4 A
- Current - Saturation (Isat):9A
- Shielding:Unshielded
- DC Resistance (DCR):42mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:-
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.730" L x 0.600" W (18.54mm x 15.24mm)
- Height - Seated (Max):0.450" (11.43mm)
