RLF12560T-2R7N110
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.7UH 11.5A 5.4 MOHM
- CategoryFixed Inductors
- Datasheet RLF12560T-2R7N110 Datasheet
-
ECAD Model
- Share
In Stock: 155
Can ship immediately
Pricing:
- 1$2.44
- 500$1.275
- 1,000$1.1625
- 2,500$1.125
- 5,000$1.0875
Quote It
Technical Details
- Series:RLF
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Last Time Buy
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:2.7 µH
- Tolerance:±30%
- Current Rating (Amps):11.5 A
- Current - Saturation (Isat):14.4A
- Shielding:Shielded
- DC Resistance (DCR):5.4mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.504" L x 0.492" W (12.80mm x 12.50mm)
- Height - Seated (Max):0.236" (6.00mm)
